Lehle Mono Volume Pedal

Lehle Mono Volume Pedal – Premium Magnetic Volume Control with Boost & Buffered Direct Out

The Lehle Mono Volume is a premium active volume pedal designed for players who want exceptionally smooth, precise volume control without the wear, noise, or tonal compromises associated with conventional potentiometer-based volume pedals.

Instead of a traditional mechanical pot, the Mono Volume uses a German-made Hall-effect magnetic sensor that measures the position of the pedal and controls a high-quality Blackmer® VCA (Voltage Controlled Amplifier). This allows extremely precise, virtually wear-free operation while eliminating the typical noise and adjustment issues of conventional volume pedal designs.

Across the entire control range, the Lehle Mono Volume is designed to preserve the full frequency spectrum of the connected instrument. Its input and output impedances remain constant as the pedal moves, helping avoid the loss of high frequencies that can occur with traditional potentiometer-based volume pedals.

The volume range extends from approximately -92 dB to 0 dB, while the recessed gain control can add up to approximately +10 dB of boost. At its minimum setting, the gain control provides unity gain when the pedal is fully forward; turning it up increases the maximum output level without changing the frequency response.

A separate buffered DIR output sends the original input signal at the same level and can feed a tuner, second amplifier, or other destination without loading down the source signal. This also makes silent tuning easy: rock the main VOL output down to mute your amp while the tuner continues receiving signal from the DIR output.

The Mono Volume works with a wide range of instruments and signal types, including electric guitar and bass, acoustic instruments with pickup systems, and both active and passive pickups. Its approximately 2 MΩ input impedance allows it to accept both high- and low-impedance sources.

Mechanically, the pedal is built for smooth, stable operation. Low-friction high-performance polymer bearings provide a fluid feel, and an adjustment screw lets you fine-tune the pedal resistance to make the action heavier or lighter to suit your preference.

Flexible pedalboard power: The Lehle Mono Volume requires an external power supply and accepts 9–15V DC or 7–12V AC at 50 mA. A standard 9V center-negative pedalboard supply works fine, but the pedal itself is not polarity-sensitive. Incoming power is internally rectified, filtered, stabilized, and brought to 18V, helping provide excellent headroom and a total dynamic range of 110 dB. Power supply is not included.

Features

• Premium active mono volume pedal for guitar, bass, acoustic instruments, and more
• German-made Hall-effect magnetic sensor
• Virtually wear-free operation with no conventional mechanical volume potentiometer
• Premium Blackmer® VCA design
• Maintains consistent input and output impedance throughout the pedal's travel
• Designed to preserve the full frequency spectrum of the connected instrument
• Volume range from approximately -92 dB to 0 dB
• Adjustable gain with up to approximately +10 dB of boost
• Buffered DIR output for tuner, second amp, DAW/interface, or other destination
• Allows silent tuning when the main VOL output is muted
• Compatible with active and passive pickups and both high- and low-impedance sources
• Low-friction polymer bearings for smooth pedal movement
• Adjustable pedal resistance
• Can be mounted to a pedalboard with Velcro or the supplied fixing screws
• Accepts 9–15V DC or 7–12V AC external power
• Polarity-independent power input
• Made and tested in Germany

Specifications

• Input Impedance: 2 MΩ
• Output Impedance: 500 Ω
• Frequency Range: 50 Hz–100 kHz (controls in middle position)
• Volume Range: Approximately -92 dB to 0 dB
• Maximum Gain: +10 dB
• Power: 9–15V DC or 7–12V AC
• Power Consumption: 50 mA
• Power Supply: External power supply required; not included
• THD: <0.05% at 1 kHz, -10 dBu
• Signal-to-Noise Ratio: -102 dB at 1 kHz, 0 dBu, A-weighted
• Maximum Level: 3V RMS, approximately 12 dBu at 12V input
• Dynamic Range: 110 dB
• Dimensions: 10.24" x 3.94" x 2.6" (26 x 10 x 6.6 cm)
• Weight: 3.57 lb (1,620 g)

Why choose the Lehle Mono Volume?
Most traditional volume pedals rely on a mechanical potentiometer that can wear over time and may alter impedance and high-frequency response as the pedal moves. Lehle's magnetic sensor and VCA-based design takes a different approach, delivering smooth control, consistent signal handling, long-term reliability, and excellent tonal transparency. For players who consider a volume pedal an important part of their signal path rather than just a utility accessory, the Mono Volume is a serious, professional-grade solution.
