Boss OD-200 Hybrid Overdrive Guitar Pedal

With the OD-200 Hybrid Drive, the famous BOSS drive tone experience reaches an expanded level of versatility and creative control. This inspiring pedal packs over 30 years of innovation into a sleek design that lets you build custom tones with ease. Choose from 12 primary drive modes and fine-tune with a powerful three-band EQ, boost circuit, and advanced gate. And with 128 user memories, full MIDI support, and variable routing options, the OD-200 is a core tone machine ready to support any performance setup.

Versatile drive tones with bold sound and feel

The OD-200’s hybrid analog/digital design provides exceptional sound and response, delivering the perfect blend of classic stomp feel and modern versatility. Twelve modes offer everything from organic amp-like overdrive to heavy distortion and saturated fuzz, with precise gain tuning via the High and Low controls. And unlike other drives that color your tone, the OD-200’s wide-ranging three-band EQ lets you shape the sound to perfectly match your rig and personal style.

Customize and explore

The OD-200’s powerful gain-boost circuit can be placed before or after the drive section, enabling you to shape tone or increase volume depending on your needs. Use the Boost to add bite and focus for solos, or saturate the front of a clean amp to produce your own signature crunch. There’s also a handy Gate for taming high-gain noise, which is easy to adjust on the panel or assign to turn on/off via an external footswitch.

Maximum control

All 200 series pedals feature a multi-function footswitch with customizable behavior. You can set it for standard on/off, switch memory patches, tap tempo for time-based effects, or even real-time parameter control. There’s also support for external footswitches and expression pedals, plus full MIDI control via TRS jacks. With 128 user memories, you can recall your favorite setups instantly.

High-end sound

The OD-200 delivers class-leading performance with 32-bit AD/DA, 32-bit floating-point processing, and a 96 kHz sampling rate. This means you get powerful tone shaping and pristine audio quality in one road-ready unit that easily adapts to any stage or studio environment.

• 12 analog-inspired drive modes with advanced hybrid tone generation
• Dual-stage Boost circuit with pre/post drive routing options
• Advanced gate circuit with responsive, musical feel
• Three-band EQ for deep tone shaping
• Save and recall 128 user memories
• Customizable footswitch for bypass, memory change, or real-time control
• Support for external footswitches and expression pedals
• Full MIDI I/O with mini TRS jacks
• Premium BOSS sound with 32-bit AD/DA, 32-bit floating point processing, and 96 kHz sampling
• Micro USB jack for firmware updates
• Runs on PSA-series AC adapter or three AA batteries

• Sampling Frequency: 96 kHz
• AD/DA Conversion: 32 bits
• Processing: 32-bit floating point
• Memory: 127 + Manual
• Nominal Input Level: INPUT: -10 dBu; RETURN: -10 dBu
• Maximum Input Level: INPUT: +7 dBu; RETURN: +7 dBu
• Input Impedance: INPUT: 1 M ohm; RETURN: 1 M ohm
• Nominal Output Level: OUTPUT: -10 dBu; SEND: -10 dBu
• Maximum Output Level: OUTPUT: +7 dBu; SEND: +7 dBu
• Output Impedance: OUTPUT: 1 k ohm; SEND: 1 k ohm
• Recommended Load Impedance: OUTPUT: 10 k ohm or greater; SEND: 10 k ohm or greater
• BYPASS: Buffered bypass
• Controls: ON/OFF switch, MEMORY/TAP switch, DRIVE knob, BOOST knob, GATE knob, LEVEL knob, LOW knob, MIDDLE knob, HIGH knob, TYPE knob, BOOST switch, GATE switch, PARAM knob
• Display: Graphic LCD (128 x 32 dots, backlit LCD)
• Indicators: A, B, C, D (Memory) indicators
• Connectors: INPUT (mono) jack, OUTPUT (mono) jack, SEND jack, RETURN jack, CTL 1,2/EXP jack: 1/4-inch TRS phone type, MIDI IN/OUT mini TRS jacks, USB Micro-B, DC IN jack
• Power Supply: Alkaline battery (AA, LR6) x 3 or AC adaptor (PSA series: sold separately)
• Current Draw: 170 mA
• Expected battery life under continuous use: Approx. 7 hours (when using alkaline batteries)
• Expected battery charging time: —
• Dimensions: 101 mm x 138 mm x 60 mm (62 mm with rubber feet)
• Weight (including batteries): 650 g
• Accessories: Owner’s manual, Leaflet "USING THE UNIT SAFELY", Alkaline batteries (AA, LR6) x 3
• Options (sold separately): AC adaptor (PSA series), Footswitch (FS-5U, FS-6, FS-7), Expression pedal (FV-500H, FV-500L, EV-30, EV-5), MIDI TRS cables
• 0 dBu = 0.775 Vrms
